GE IS200DTAIH1ABB - High-Performance Control Interface Module
2025-01-13 BY
IN Industry trends

IS200DTAIH1ABB|Analog input/output terminal board

What does conformal PCB coating include?

The conformation coating of the IS200DTAIH1ABB Simplex analog input/output terminal board is a thin layer of PCB protection for chemical applications that extends to the entire base PCB of the IS200DTAIH1ABB Simplex analog input/output terminal board device.
How is the IS200DTAIH1ABB Simplex Analog Input/Output Terminal Board installed?

This IS200DTAIH1ABB simplex analog input/output terminal board product is mounted on a DIN rail assembly as it has a plastic mounting backplane.
About IS200DTAIH1ABB
The IS200DTAIH1ABB is a GE component created for the Mark VI system. The Mark VI is a gas/steam turbine management system released under the Speedtronic family name. The series has been used in various iterations of turbine management since the 1960s. The Mark VI family of fan control systems comprising this IS200DTAIH1ABB Simplex analog input/output terminal board product must be described as a considerable functional improvement over the previous industry standard Mark V family of fan control systems with nearly the same full family name. Because the Mark VI series adds to the gas and steam turbine setups already adopted by the Mark V Series the possible functional applications of wind turbines with an alternative energy focus. The IS200DTAIH1ABB simplex analog input/output terminal board PCB product’s Mark VI turbine control system family was also welcomed as one of the final GE Mark product families due to its independent status. To use the patented Speedtronic control system technology in many products.
GE IS200DTAIH1ABB - High-Performance Control Interface Module

Hardware tips and specifications

The Mark VI has Ethernet communication capabilities and includes onboard diagnostics (limit checks) in both hardware and software. The IS200DTAIH1ABB is a simplex analog input/output terminal board. It is a compact input board for analog signals. The board is mounted in a plastic bracket that allows the PCB to be mounted on the DIN rail. The board has 10 analog inputs and 2 analog outputs. The output is 0-20mA, but one can be configured for 0-200mA current by reconfiguring the jumper. The IS200DTAIH1ABB has a 37-pin connector with latch fasteners. This is labeled JR1. The board has a terminal board (TB1) with 48 screw connections. The terminal block is permanently installed on the circuit board. Terminal blocks usually use shielded twisted pair #18 AWG wire. Note that screws 43/44 are designated for ground (SCOM) connections. Ground cables should be as short as possible. The board has 21 jumper switches; These are labeled JP1A/B-JP10A/B (20) plus JP0. The board also includes a variety of capacitors, resistors, and integrated circuits, as well as four small panels. Jumpers on the board are used to configure current and voltage.

IS200DTAIH1ABB Technical support is provided by GE. For information about this PCB, its components, or installer, please refer to the manual, user guide, and data sheet. Unfortunately, for the IS200DTAIH1ABB Simplex Analog input/Output Terminal Board Personalization product page here, the IS200DTAIH1ABB Simplex analog input/Output Terminal board device is not surrounded by a lot of original printed online instruction manual material. Because the Mark VI turbine control system family faced a concerted series of copyright infringements in the years following the launch of its original GE product family. In this case, the IS200DTAIH1ABB Simplex analog input/Output terminal board function Product number itself may be introduced as an appropriate supplemental source of hardware component and component specification information for the IS200DTAIH1ABB Simplex analog input/Output terminal board. Because it indirectly asserts many related IS200DTAIH1ABB Simplex analog input/output terminal board hardware details through a series of continuous function naming elements. For example, the product number of the IS200DTAIH1ABB Simplex analog input/output terminal board product begins with the dual-function IS200 series label assembly number, The IS200DTAIH1ABB Simplex analog input/output terminal board product is a normal Mark VI series assembly version and its domestic original manufacturing location. Some other IS200DTAIH1ABB Simplex analog input/output terminal board details indicated by this medium include:

DTAI Functional Products acronym
The first group of Mark VI series groups
Conformal PCB coating style
Triple discount product revision form

GE IS200DTAIH1ACC Digital Signal Processor Interface Module
2025-01-13 BY
IN Industry trends

IS200DTAIH1ACC|Turbine control board

It has 12 digital input ports and 16 digital output ports. It also has an RS-485 interface for communication and a USB interface for diagnostics.

The board can be used to control various turbine parameters, including speed, temperature and pressure. It can also be used to perform various control functions such as start, stop, and fail-safe.

The board is mounted with standard DIN 43880 rails. It requires a 24 V DC power supply.

The GE IS200DTAIH1ACC Turbine Control Board is a powerful device that can be used to control a variety of turbines. It is a key component of the GE Mark VI turbine control system.
GE IS200DTAIH1ACC Digital Signal Processor Interface Module

The function of the PLC internal input circuit is to send the voltage signal provided by the PLC external circuit (such as stroke switch, button, sensor, etc.) that meets the requirements of the PLC input circuit to the PLC internal circuit through the photoelectric coupling circuit. input
The circuit usually improves the anti-interference ability by means of photoelectric isolation and resistance and capacitance filtering, and the input response time is generally between 0.1 and 15ms. According to the different forms of the input signal, it can be divided into analog /O unit and digital sub-unit /0 unit
Big class. According to the different forms of input units, it can be divided into basic I/O units and extended I/O units.

GE IS200HSLAH2ADE HS SLR LNK Interface Module
2025-01-13 BY
IN Industry trends

IS200HSLAH2ADE|Serial link interface board

Are the three important revisions of this IS200HSLAH2ADE appliance considered backward compatible?

The three versions of this IS200HSLAH2ADE product are not backward compatible because only the first two versions can have this compatibility because their functional product version styles match.
Is this PCB mounting in the standard VME rack mount structure of the IS200HSLAH2ADE Mark VI series?

Nooooo. Since this IS200HSLAH2ADE product lacks the unique VME rack mount panel, it can be assumed that the IS200HSLAH2ADE product is not installed in any VME rack.
Is this Level E artwork configuration revision for the IS200HSLAH2ADE product a common style for the Mark Series revision?

Nooooo. The Level E illustration configuration of the IS200HSLAH2ADE product is a relatively rare style in the Mark VI series revisions.
About IS200HSLAH2ADE
The IS200HSLAH2ADE is a printed circuit board component manufactured for the Mark VI family of turbine control systems. MKVI is one of the final systems distributed by GE in the Speedtronic family for managing heavy-duty gas/steam turbine systems. MKVI is a complete platform for protecting, controlling, and monitoring these types of turbine systems, as you are likely to decipher them by their full extended family name alone. The MKVI was designed by GE as a modular, adaptable and scalable system that can add or remove modules to meet the needs of the respective turbine. The Mark VI family of turbine control systems that includes this IS200HSLAH2ADE product has been able to attract sustained traction in the larger automated industrial community promotion market, simply because it was one of the final Mark product families developed by GE. Patented Speedtronic control system technology is used in a wide range of different products.
GE IS200HSLAH2ADE HS SLR LNK Interface Module

Hardware tips and specifications

The IS200HSLAH2ADE is an HS SLR LNK interface board. The board is mounted on the top and bottom surfaces of the board. This is a small board with a jack connector on the top. It has two transformers (Halo TG 110-EO 50N5) as well as six inductors, several transistors, and many resistors, capacitors, and diodes. The board features more than 20 integrated circuits, including a field programmable gate array for U1. Additional connectors, resistors, transistors and capacitors on the underside; These are just a small part of a larger insulation and voltage protection strategy involving a large number of Mark VI Series standardized voltage limiting hardware components and component specifications

Since the common Mark VI series PCB assembly version of this IS200HSLAH2ADE product does not use an additional front panel, it can be assumed that this IS200HSLAH2ADE product is not installed in the typical VME rack-mount assembly of the Mark VI series. The IS200HSLAH2ADE Feature Product number can be described as the primary source of hardware component and component specification information for the IS200HSLAH2ADE Board. Because the IS200HSLAH2ADE product lacks the original instruction manual materials available for this IS200HSLAH2ADE online personalized product page; May be a symptom of the IS200HSLAH2ADE device having previously stopped production from GE. The IS200HSLAH2ADE feature product number begins with the dual Feature IS200 series label and delegates many important hardware details through a series of continuously developed feature naming components. The dual-function label beginning with the IS200HSLAH2ADE functional product number describes both the normal Mark VI series components of the IS200HSLAH2ADE serial link interface board and the status of its domestically manufactured product. Some other relevant details embedded in this IS200HSLAH2ADE feature number include the following for IS200HSLAH2ADE products:

HSLA Functional products
Conformal PCB coating style
Group 2 Mark VI Series product group
Three fold revision table

GE IS200SAMBH1ABA Acoustic Monitoring Terminal Board for Mark VI and Mark VIe Systems
2025-01-13 BY
IN Industry trends

IS200SAMBH1ABA|Acoustic monitoring terminal board

What is involved in the conformal PCB coating style for the IS200SAMBH1A circuit board?

The conformal PCB coating of the IS200SAMBH1A device is a thin layer of full-surface PCB daily wear protection that is chemically applied to the entire substrate of the IS200SAMBH1A product.
Is the Class A feature product version of this IS200SAMBH1A device a common style for Mark VI series versions?

Yes. The Class A major feature version of the IS200SAMBH1A device is the most common product version in GE’s entire Mark product suite.
About IS200SAMBH1A
The IS200SAMBH1A is a PCB (printed circuit board) device manufactured by GE for its Mark VI and Mark VIe systems. These systems, released by GE, are designed to improve the efficiency of its gas and steam turbines through reliable management. Both are TMR (Triple Modular Redundancy) systems that allow multiple backups of critical control and protection parameters. This IS200SAMBH1A product may belong to the Mark VIe family and is an upgraded version of the previous Mark V series, as its possible applications also extend to alternative energy Settings for wind turbine gears. However, the IS200SAMBH1A product’s Mark VI turbine control system family still attracts some consistent demand in the current automation industry, as it is one of the final GE Mark product families to be developed utilizing patented Speedtronic control system technology. The technology was first introduced with the release of the Mark I and has remained so ever since.
GE IS200SAMBH1ABA Acoustic Monitoring Terminal Board for Mark VI and Mark VIe Systems

Hardware tips and specifications

The IS200SAMBH1A is an acoustic monitoring terminal board. The double terminal board adds 18 inputs to the acoustic monitoring system through 36 terminals located on the terminal block for connecting two-wire inputs. The board also has a terminal board with 36 terminal connections for adding 2-wire buffer outputs for a total of 18 outputs. These outputs typically monitor voltage signals. The IS200SAMBH1A is fitted with a passive electromagnetic interference (EMI) filter to prevent high-frequency noise from external sources. The IS200SAMBH1A design has an additional metal frame that surrounds all four edges of the PCB. The frame has multiple flanges, including a top hat flange placed along each long side of the board that has been drilled with mounting notches or holes. The board surface is marked with various codes, including FA/00. The board assembly and the aforementioned frame are connected via bracket and screw mounting. The board measures 9.1 “x 5.625”. Cooling is achieved by air convection. The IS200SAMBH1A is filled with many jumper switches. These are used to connect SigX lines to a constant current source. For more information about the board, its components, operation, and installation, please refer to the manufacturer’s User Guide and manual.

The IS200SAMBH1A product is a highly voltage-sensitive Mark VI series product, and by using the Mark VI series standardized voltage limiting hardware components and component specification selection, including different iterations of Mark VI Series capacitors, diodes, resistors, and finally integrated circuit components, The high-voltage intensive features of the Mark VI series have been enhanced. The above information on this IS200SAMBH1A personalized product page here does say more about the lack of original GE instruction manual materials available online for this IS200SAMBH1A device than it does about its true importance to the IS200SAMBH1A product. Given this identified lack of documentation, the IS200SAMBH1A product’s functional product number can actually be identified as the primary source of IS200SAMBH1A Board hardware component and component specification information, as it encodes relevant hardware information through a series of GE designed functional naming blocks. One of these blocks is the dual-function IS200 segment, which is indirectly responsible for describing the normal Mark VI series components of this IS200SAMBH1A product and its domestic original manufacturing location. Some other relevant hardware details stored in the IS200SAMBH1A functional product number include the following PCBS:

SAMB Functional Products Acronym
Conformal PCB coating style
The first group of Mark VI series products
Class A Functional Product revision

GE IS200SPROH1AAB Terminal Board for Mark VI Series Industrial Turbine Control Systems
2025-01-13 BY
IN Industry trends

IS200SPROH1AAB|Gas turbine circuit board module

The IS200SPROH1AAB-MRP663860 is a circuit board manufactured by GE primarily to replace components in its Speedtronic Mark system.

It acts as a digital signal processor control board and is available in a variety of versions.

The board consists of a variety of components from small to large, and the square design makes it easy to install and use.
GE IS200SPROH1AAB Terminal Board for Mark VI Series Industrial Turbine Control Systems

In addition, the board is used as a digital signal processor board in Mark VI systems with Ethernet-enabled tri-mode redundant control options, proprietary software such as CIMPLICITY, and a Windows-based operating system.

This makes it highly compatible and interoperable in industrial automation and process control systems.

GE IS230SNRTH2A, IS200SRTDH2ACB: Advanced RTD Input Module for Precision Temperature Measurement
2025-01-13 BY
IN Industry trends

IS200SRTDH2ACB|Mark VI series printed circuit boards

The IS200SRTDH2ACB is a simplex analog input terminal board manufactured and designed by General Electric as part of the Mark VIe family for distributed control systems. The simplex Analog Input (STAI) terminal board is a small analog input terminal board that can be connected to a battery pack and supports 10 analog inputs and 2 analog outputs. 2-wire, 3-wire, 4-wire, or transmitters with an external power supply can all be connected to 10 analog inputs. Two 0-20 mA 0-20 mA jumpers are available for configurable analog outputs, one of which supports 0-200 mA currents. The board is only available in simplex form. The terminal type is high-density Euro Block. The board is identified to the battery pack by an onboard ID chip for system diagnosis.
GE IS230SNRTH2A, IS200SRTDH2ACB: Advanced RTD Input Module for Precision Temperature Measurement

STAI installation:

A metal plate bracket mounted on the DIN rail carries the STAI along with the plastic insulator. STAI plus insulators can also be mounted on a metal plate assembly and then secured directly to the cabinet. There are two different types of Euro-block terminals available:

STAI 1 has a permanently mounted terminal with 48 terminals.
The right Angle joint on the STAI 2 accepts a variety of easily accessible pluggable terminals, with a total of 48 terminals.
Shielded twisted pair (#18 AWG) wire is usually used. There is an I/O cable shield terminal next to the terminal.
The following analog input and output types can be accepted:

Two-wire transmitter with analog input.
Three-wire transmitter with analog input.
Four-wire transmitter with analog input.
External powered transmitter with analog input.
Analog inputs, 5 V and 10 V DC.
0-20 mA current analog output.
Analog output, current 0-200 mA.

GE IS200TRLYH1BGF - Termination Relay Card for Mark VI Gasoline and Steam Turbine Controls
2025-01-13 BY
IN Industry trends

IS200TRLYH1BGF|Relay terminal boards used in Mark VI turbine control systems

The IS200TRLYH1B is a terminal relay card manufactured by GE for the Mark VI fan control system. This board is the “B” version of the TRLY terminal relay board and has the following characteristics:

Voting coil drive feedback
Socket type sealed mechanical relay
MOV inhibition
48 fence terminals
GE IS200TRLYH1BGF - Termination Relay Card for Mark VI Gasoline and Steam Turbine Controls
Physical description of IS200TRLYH1B:

The left edge of the IS200TRLYH1B contains two (2) large black terminals. Each terminal has twenty-four (24) silver metal terminals. There are forty-eight (48) terminals in total. Each terminal block is labeled with white lettering. Four (4) connector ports have been placed on the right bezel of the IS200TRLYH1B. Three (3) connector ports are aligned vertically at the edges, with the last one parallel to the connector port at the bottom. Near the center of the IS200TRLYH1B, there is a long row of white and black relays with cube-shaped transparent LIDS. These components have been connected to the PCB by black wire. Each relay has a round black transistor on either side. Paired with each transistor is a round red MOV or metal oxide varistor. Five (5) of these relays are arranged vertically on the top half of the IS200TRLYH1B. Five (5) additional relays have been aligned on the bottom half of the PCB.

GE IS200TSVCH2ADC MRP061873 - High-Performance Turbine Speed Control Board
2025-01-13 BY
IN Industry trends

IS200TSVCH2ADC|Analog input pad

The IS200VAICH1DAB model is manufactured by GE to simulate an input/output board system for TMR or simplex applications in the Mark V. When used in a TMR system configuration, the terminal board, TBAIH1C, or STAI board from the connection will fan out to three VME racks: T, R, and S, each containing a VAIC board. The output signal Board on the VAIC will be made up of proprietary circuits, using all available VAIC boards to create the required current. If there is any IS200VAICH1DAB model rack failure on the VME, the faulty VAIC model will be removed from the output and the rest of the VAIC board can continue to provide the correct current. When the model is configured for the simplex method, the connected terminal plates will feed into one of the VAIC models, thus providing all current to the output. In the operation of the IS200VAICH1DAB model, it will control four analog outputs and accept up to 20 analog inputs. This model has an analog multiplexer, A/D converter, D/A converter, and signal regulator. This model has two analog inputs, ± 1 mA or 4-20 mA, which are connected by a jumper terminal board. The analog output circuit is divided; Two outputs can be configured to be 0-200 mA or 4-20 mA, while the other outputs are only 4-20 mA. Both the input and output of this IS200VAICH1DAB model contain high suppression circuits that protect against high-frequency noise and surges. DAB module is a module for industrial automation and process control, with digital input/output and analog input/output functions. It can be connected to industrial controllers (such as PLCS) to implement various control logic and data processing functions.
GE IS200TSVCH2ADC MRP061873 - High-Performance Turbine Speed Control Board
The features of the IS200VAICH1DAB module are as follows:
High reliability: This module uses high-quality raw materials and advanced production processes, with reliability and stability, to ensure long-term stable operation. Multiple functions: This module has a variety of functions, such as digital input/output and analog input/output, to meet a variety of industrial automation and process control needs. Easy to configure and use: The module has a simple and easy-to-use configuration software and programming interface, making it easy for users to configure and use. Wide applicability: The module is suitable for various industrial automation and process control fields, such as power, chemical, pharmaceutical, etc.

GE IS200TSVCH2AED: Terminal Board for GE PLC Systems
2025-01-13 BY
IN Industry trends

IS200TSVCH2AED|Digital I/O module

MKVI includes an operating interface designed for personal computers with Microsoft Windows operating systems, which supports GE CIMPLICITY.
Graphics and General Electric Control System toolbox
IS200TSVCH2AED
Ethernet connectivity is achieved through socket connectors that allow the board to connect to other Mark VI, Mark VIe, or EX2100 excitation controllers.
And maintain and operate station interface GE IS200TSVCH2AED fan control module
GE IS200TSVCH2AED: Terminal Board for GE PLC Systems

The GE IS200TSVCH2AED is an analog input module commonly used in industrial automation and control systems. Here is some basic information about this module:
Manufacturer: General Electric (GE) is a global industrial conglomerate that offers a wide range of industrial automation and control system products.
Model: IS200TSVCH2AED is the model number or model code for this analog input module. This model is often used to uniquely identify this particular module.
Analog input module: Analog input module is a part of industrial automation system for receiving and processing analog signals. These signals usually represent continuous changes, such as temperature, pressure, flow rate, voltage, etc.
Function: The main function of this module is to receive, measure and process analog input signals. This allows them to monitor multiple analog signals simultaneously.

GE FANUC IC693MDL753: High-Performance 32 Channel 24 Volt Output Module
2025-01-10 BY
IN Industry trends

IC693MDL753H|90-30 series positive logic discrete output module

Brand GE Fanuc
Series Series 90-30
Manufacturer GE Fanuc; Emerson Automation (Current) Emerson Automation (current)
Series Series 90-30
Part number IC693MDL753
Product description Discrete output module
Product description Discrete output module
Product Type Digital I/O
Number of channels 32 (32)
Nooooo. Number of output groups four (4)
GE IC693MDL753H Output Module: Advanced Control Solutions for Industrial Automation

The IC693MDL753 is a digital output module of the 90-30 series Programmable Logic Controller (PLC) series. The module has thirty-two (32) positive logic output channels that produce an output voltage range of 102-28.8 with a nominal voltage of 12-24 VDC. The IC693MDL753 was previously manufactured by GE Fanuc Automation and has now been acquired by Emerson Automation. The module comes specifically with output groupings, four (4) groups of eight (8) outputs each. Each output group has a voltage of 250 volts and 100 volts between the field side and the logical side or optical isolation. The IC693MDL753 has an output current rating of 0.5 amps per point, with a maximum of 4 amps per group and 3 amps per group of common pins. It produces a surge current of 5.4 amps for 10 milliseconds while the on-voltage drops to 0.3 VDC. The off state leakage current is 0.1 mA, while the on and off response time, which is typical for the conversion of two signals, is 0.5 ms. The IC693MDL753’s internal power consumption is 260 mA from a 5-VDC backplane. The IC693MDL753 is compatible for use as both local and distributed I/O modules. It can be installed in any available slot in the chassis, except for specified CPU, communication adapter, and dedicated module slots. The IC693MDL753 occupies one slot and can be installed in as many slots as required, which is limited by the I/O capacity and memory of the host controller. To connect electrical loads to this discrete output module, the IC693CBL315 recommended manufacturer’s cable assembly.

The IC693MDL753 I/O module is a 32-point digital I/O module. The IC693MDL753 I/O module was developed by GE Fanuc for the 90-30 series of GE programmable logic controllers or PLCS. When using the 5-volt DC voltage supplied by the PLC backplane, the module has a peak current consumption rating of 260 mA. When each output point is ON, it consumes 16 mA of current, and the LED indicator at each output point consumes 4.7 mA of current. The 32 points were arranged into four groups of eight outputs each. When operating at 24 volts DC, each set of points consumes 16.5 milliamps of current when all eight outputs in the group are ON. When operating at 12 volts DC, each group consumes 9.6 mah of current when all eight outputs in the group are on. The inrush current of the IC693MDL753 I/O module is 5.4 amps. Both the on-off response time and the turn-off response time are 0.5 ms. The maximum output current of each point is 0.5 amps, and the maximum output current of each group is 4 amps. The output voltage range of the IC693MDL753 I/O module is 10.2 to 28.8 volts DC. The output on the module is positive logic output. The output switches the load on the positive side of the power supply and provides current to the load. Each set of output points can be used for different loads. The optocoupler provides isolation between the logical side and the field side of the IC693MDL753 I/O module. When the PLC’s CPU stops, all module outputs are forced into the OFF state. The connection to the output circuit is made through two 24-pin male connectors on the front of the module.
