Number of Channels:16
Channel Configuration:Differential or Single-ended
Operating Voltage:120/240Vac
Input Current:10mA max
Signal Type:Voltage or Current
Isolation Voltage:3000Vac
Communication Interface:RS-485
Power Consumption:Max. 10W per channel
Dimensions (WxDxH):2.5 x 4.7 x 1.5 inches
Weight:0.5 lbs
Mounting:Panel or DIN Rail
The AB 1794-IM16 is engineered with advanced signal conditioning technology to ensure accurate and reliable AC input measurements, making it an indispensable component for critical industrial processes. This module supports a wide range of voltage inputs from 85 to 264 Vac, allowing it to adapt to various industrial environments and applications.
Featuring 16 input channels, each capable of handling up to 5 mA of current, this module offers a versatile solution for monitoring multiple sensors or devices simultaneously. Its True RMS signal conditioning ensures precise readings even under fluctuating input conditions, enhancing the reliability of your automation system.
With compatibility for EtherNet/IP, DeviceNet, and ControlNet networks, the AB 1794-IM16 facilitates seamless integration within complex industrial automation infrastructures, improving efficiency and reducing downtime. Its DIN rail mounting design ensures easy installation and maintenance in harsh industrial settings.
Designed for operation within a temperature range of -20°C to +60°C and withstanding humidity up to 95% non-condensing, this module is built to withstand the rigors of industrial environments. The IP20 enclosure provides basic protection against dust and splashes, ensuring durability and reliability in varied conditions.
For users seeking a robust and flexible AC input solution that integrates seamlessly into their existing automation systems, the AB 1794-IM16 is the ideal choice. Its combination of high performance, compatibility, and rugged design makes it a preferred selection for enhancing the precision and efficiency of industrial control applications.
