Control Power Nominal:20 VA
Control Power Maximum:65 VA
Control Power Input Range:110 to 250 VDC, 100 to 240 VAC at 50/60 Hz
Dimensions:Approx. 12 in H x 5 in W x 8 in L
Ground Current Input Frequency:20 to 100 Hz
Insulation:Class I
Phase Current Input Conversion:True RMS, 1.04 ms/sample
Weight:Approx. 4.5 kg
Optional Features:Metering, Twelve Built-in RTD Ports
The GE 369-HI-R-M-0-0-0 Motor Management Relay is a robust solution for managing and protecting medium-sized motors and their associated equipment. This advanced relay leverages waveform capture technology to analyze motor performance in real-time, ensuring optimal operation and reduced downtime. With built-in metering capabilities, users can monitor critical parameters such as voltage, current, and temperature, making it easier to identify potential issues before they become serious problems.
Equipped with twelve RTD (Resistance Temperature Detector) inputs, the relay provides accurate temperature monitoring for each phase, enhancing overall motor reliability. Additionally, the relay supports non-isolated RS232 and RS485 communication ports, enabling seamless integration with existing industrial control systems and networks. The differential switch time delay is less than 200 ms, ensuring rapid response to critical events.
Designed for durability, the relay operates within a wide temperature range from -40°C to +60°C and can be stored in temperatures ranging from -40°C to +80°C, making it suitable for harsh industrial environments. Its compact dimensions of approximately 12 inches in height, 5 inches in width, and 8 inches in length make it easy to install in tight spaces without compromising on performance.
