Frequency Range:0 Hz to 50 MHz
Output Amplitude:0.1 Vpp to 10 Vpp
Waveform Types:Sine, Square, Triangle, Pulse, Ramp
Phase Shift:0° to 360°
Amplitude Accuracy:±1% of setting ±0.1 Vpp
Frequency Resolution:1 µHz
Output Impedance:50 Ω
Harmonic Distortion:≤ -60 dBc
Designed for precision and reliability, the Tektronix 5A18N Function Generator delivers accurate and stable waveforms across a wide frequency range. This makes it an essential tool for engineers and technicians working in electronics manufacturing and R&D.
The generator supports multiple waveform types including sine, square, triangle, ramp, noise, and arbitrary waveforms, offering unparalleled flexibility for diverse testing scenarios.
With a resolution of 14 bits, the Tektronix 5A18N ensures precise waveform generation, making it suitable for high-precision applications. The output amplitude ranges from ±10 Vpp to ±20 Vpp, depending on the load conditions, ensuring compatibility with a variety of devices.
The phase shift capability allows users to adjust the phase of the generated waveforms from 0 to 360 degrees, enabling precise control over signal timing. The synchronization feature supports both internal and external triggering, enhancing its utility in complex test setups.
Constructed with durable materials and advanced technology, the Tektronix 5A18N is built to withstand the rigors of industrial environments. Its user-friendly interface simplifies operation, allowing even novice users to generate high-quality waveforms effortlessly.
