Frequency Range:0 Hz – 20 MHz
Waveform Types:Sine, Square, Triangle, Ramp, Pulse, Noise, Arbitrary
Resolution:14-bit vertical resolution
Output Amplitude:2 Vpp into 50Ω
Output Impedance:50Ω
Sampling Rate:up to 40 MSa/s
Memory Depth:16 kpts
Interface:USB, LAN, GPIB
The Tektronix 5b42 Arbitrary Waveform Generator (AFG1062) is designed for professionals who require precise and flexible waveform generation capabilities. Its compact and robust design makes it ideal for both benchtop and field applications.
This generator provides a wide range of waveform types, from simple sine waves to more complex arbitrary waveforms, making it suitable for a variety of testing scenarios. Users can easily create custom waveforms using the intuitive front panel or via remote control.
With a high-resolution display and easy-to-navigate controls, the AFG1062 ensures that users can quickly set up and adjust their waveforms without any hassle. It supports multiple trigger sources, allowing seamless integration into automated test systems.
The connectivity options, including USB, LAN, and GPIB interfaces, enable users to connect and control the device remotely, facilitating efficient data transfer and system integration. The device is also equipped with advanced features like phase shift control and high sampling rates, ensuring accurate and reliable waveform generation.
Designed with reliability and ease-of-use in mind, the Tektronix 5b42 AFG1062 offers a comprehensive solution for waveform generation needs. Whether you are an engineer working in electronics testing or a researcher conducting experiments, this instrument delivers the precision and performance required to achieve your goals.
