Model Type:Analog I/O Module
Model Number:3700a
Manufacturer:TRICONEX
Voltage:0-5V, ±6%
TMR Technology:Yes
Input Points:32
Input Type:Diff, DC Coupled
Isolated Points:No
Input Update Rate:55 ms
Resolution:12 bits
Accuracy:<0.15% of FSR, from 0° to 60°C
Input Resistance (Load):30 MΩ (DC), min
Power-Off Resistance:30 KΩ (DC), typical
Common Mode Rejection:-80 dB (DC-100Hz), typical
Common Mode Range:-12V to +12V peak
Leg-to-Leg Isolation:200 KΩ, typical
Normal Mode Rejection @ 8Hz:-3 dB
Normal Mode Rejection @ 60Hz:-17 dB
Normal Mode Rejection @ 120Hz:-23 dB
The TRICONEX 3700A Analog I/O Module is engineered for demanding industrial applications where precision and reliability are paramount. Its triple modular redundancy (TMR) design ensures continuous operation even under harsh conditions. This module supports up to 32 differential input channels, each with a 12-bit resolution and an accuracy of less than 0.15% full-scale range. The high common mode rejection ratio (-80 dB) guarantees stable performance in electrically noisy environments. With a fast update rate of just 55 milliseconds, it can process data quickly and efficiently, making it ideal for real-time control systems. Additionally, the TRICONEX 3700A is built with durable materials to withstand the rigors of industrial settings, ensuring long-term reliability and minimal maintenance. The compact design makes installation straightforward and space-efficient, allowing seamless integration into existing control panels.
