Tag: VM600-204-040-100-012

From the vibro-meterproduct line19″ system racks with a standard height of 6URobust aluminium construction
Modular concept allows specific cards to beadded for machinery protection and/orcondition monitoring
Cabinet or panel mounting
Backplane supporting the VME bus, theVM600Mk2/VM600 system’s Tacho, Raw andOpen collector (OC) buses, and power supplydistribution
Uses the VM600Mk2/VM600 RPS6U rack powersupply: AC and/or DC input versions
Power supply check relay

The VM600MK2/VM600 ABE040 and ABE042 systemracks are used to house hardware for theVM600Mk2/VM600 series of machinery protectionand/or condition monitoring systems, fromMeggitt’s vibro-meter@ product line.
Two types of VM600MK2/VM600 ABE04x systemrack are available: the ABE040 and the ABE042.These are very similar, differing only in the positionof the mounting brackets. Both racks have astandard height of 6U and provide mountingspace (rack slots) for up to 15 single-widthVM600Mk2/VM600 modules (card pairs), or acombination of single-width and multiple-widthmodules (cards). These racks are particularlysuitable for industrial environments. whereequipment must be pemmanently installed in 19″cabinets or panels.

The different versions of ABE04x system rackenable different mounting options to supportvarious markets and applications.
The VM600 system rack has an integrated VMEbackplane which provides the electricalinterconnections between the installedVM600Mk2/VM600 modules (cards): power supply.signal processing, input /output, relay andCPUx ‘“’rack controller”. lt also includes a powersupply check relay,available at the rear of therack, which is used to indicate that the installedRPS6U rack power supplies are operatingnormally.
Either one or two RPSoU rack power supplies canbe installed in a VM600Mk2/VM600 ABE04x systemrack.A rack with one RPS6U power supply (330 Wversion) supports the power requirements for a fullrack of modules (cards) in applications withoperating temperatures up to 50°C(122°F).
