Tag: VM600-ABE040

ABE040 is a VM600 system frame with a height of 19 “6U and 15 slots for fixing single-slot or dual-slot cards. Abe040 can accommodate a maximum of 12 functional cards (MPC4/AMC8/XMV16). Abe040 is suitable for cabinet or panel installation in industrial environments. The front of the frame CPUM/MPC4/AMC8/XMC16 and so on
Processing card and RPS6U power supply, at the back of the IOCN IOC4T/IOC8T XIO16T/RLC16 / IRC4 IO and relay CARDS, as well as the power input back, no card slot with blind plate cover.
ABE040 is an integrated VME backplane bus. The ABE040 is electrically isolated from each other, including power supply, signal processing, data collection, and input and output. The frame requires one or two RPS6U power modules to provide independent or redundant power supply. In the case of redundant power supply, the power supply of each RPS6U is 50% full. When one RPS6U power module fails, the other RPS6U power module switches to 100%. The rear of the frame has a power failure relay output, which can be set to operate when any or all power is lost.

VM600 1U 19 “frame This is used to install the machine protection and condition monitoring card of the VM600 series of VIbro-meters.
The standard height 1U 19 “frame provides mounting space for VM600 series cards. This frame is particularly suitable for industrial environments where equipment must be permanently installed in 19 “cabinets or panels.
The rack has an integrated backplane that provides integration between the electrical interconnect power unit (RPS1U) and VM600 card mounting. There is also a power status relay behind the back plate to indicate whether the power is working properly.
The RPS1U power supply is available in DC and AC power supply, with a variety of voltage ranges. IOC I/O cards are installed at the back of the frame. The clamp is provided with terminals for connection to the sensor/preprocessor and signal connection terminals for output to the external control system.
The frame is usually configured in the factory and the meter received by the user can be used directly. Or each card can also be configured on site through the configuration software for each card. Software includes VM600 MPS1, MPS2, or VibroSight ®.
